Product Description
Low Smoke Zero Halogen fixed installation, domestic and light industrial double insulated building wire.
BS 6724
Technical Specification
| Conductor |
1mm2 to 2.5mm2. Class 1 solid copper conductor according to BS EN 60228, 4mm2 to 25mm2. Class 2 stranded copper conductor according to BS EN 60228 |
|---|---|
| Insulation |
LSZH (Low Smoke Zero Halogen) |
| Sheath |
LSZH (Low Smoke Zero Halogen) |
| Rated Voltage [V] |
300 / 500 |
| Temperature Rating |
15oC to +70oC |
| Minimum Bending Radius |
10mm2 to 25mm2 – Fixed: 4 x overall diameter, Up to 6mm2 – Fixed: 3 x overall diameter |
| Core Identification |
Blue Brown |
| Sheath Colour |
Grey, RAL 7001 |
