Product Description
For use in control circuits, measuring and also in power circuits, in the automation industry, in assembly lines and production lines. Suitable in drag chains and where fast and abrupt movements exist.
CY High Flex Control Cable
For use in control circuits, measuring and also in power circuits, in the automation industry, in assembly lines and production lines. Suitable in drag chains and where fast and abrupt movements exist.
Technical Specification
| Conductor Material |
Copper, bare |
|---|---|
| Conductor Class |
Class 6 acc. to VDE 0295 or IEC 60228 |
| Core Insulation |
PVC |
| Core Identification |
screen braid of tinned copper wires VDE 0293-1 |
| Outer Sheath |
PVC |
| Sheath Colour |
Grey, RAL 7001 |
| Rated Voltage [V] |
300 / 500 |
| Testing Voltage [V] |
4000 |
| Insulation Resistance |
> 20 MΩ x k |
| min bending radius fixed [x d] |
4 |
| min bending radius moved [x d] |
7,5 |
| working temp. moved min/max [°C] |
-5°C up to +70 |
| working temp fixed min/max [°C] |
-40°C up to +70°C |
| Burning Behaviour |
IEC 60332-1: self-extinguishing and flame-retardant |
| Temperature Moved |
-5° C to 70° C |
| Temperature Unmoved |
-30° C to 80° C |
